Self aligning roller bearing 23230-CC-K-W33-SKF

150 150 270 270 96 96

Part number : 23230-CC-K-W33-SKF

SKF

Description

The Self Aligning Roller Bearing, known as 23230-CC-K-W33-SKF SKF, has an inner diameter of 150 mm, an outer diameter of 270 mm and a thickness of 96 mm.

See data sheet
N/A

  8 to 10 days

product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

02038.087.274

Description

The Self Aligning Roller Bearing, known as 23230-CC-K-W33-SKF SKF, has an inner diameter of 150 mm, an outer diameter of 270 mm and a thickness of 96 mm.

See data sheet
product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

02038.087.274

TECHNICAL DATA
  • BRAND
  • N° EAN13
    7316576601996
  • INSIDE DIAMETER
    150  MM
  • OUTSIDE DIAMETER
    270  MM
  • THICKNESS
    96  MM
  • LIMITING SPEED
    1600  RPM
  • DYNAMIC LOAD
    1080000  KN
  • STATIC LOAD
    1460000  KN
  • PACKAGING
    1
Description

The Self Aligning Roller Bearing, known as 23230-CC-K-W33-SKF SKF, has an inner diameter of 150 mm, an outer diameter of 270 mm and a thickness of 96 mm.

EXPERT ADVICE

What is a self aligning bearing?

A spherical bearing, or swinging bearing is a bearing that is able to accept that the spindle is slightly out of alignment. These bearings are regularly located in grinders or agricultural machines, regularly placed in "cast iron SN" bearings, with a shim washer and seals specific to these bearings. Attention, there are 2 important variants: • The cylindrical bore bearing, which will be mounted directly on the shaft, in force
• The tapered bore bearing, mounted with a sleeve, on an axis smaller than the bore of basis of turnover.
The tapered bore is indicated by the letter "K" in the reference.

What does the letter "K" mean in the reference?

The letter K means that the bearing has a tapered bore. It should therefore almost always be mounted with a conical sleeve. Attention, this bearing is generally mounted on an axis of 5mm less than the dimension indicated for the bearing.
